Product Advantage
Technical Specifications and Performance
Rated Current Range: Supports a current range of 30A to 100A, adaptable to various power needs, providing stable and efficient power output for different types of loads.
Diverse Casing Materials: Offers a choice between PVC and aluminum alloy materials. PVC casings are lightweight and easy to install; aluminum alloy casings provide high strength and resistance to deformation, suitable for demanding industrial environments.
Internal Conductor Material: Uses copper busbars as conductors to optimize power transmission efficiency and safety, reducing the risk of overheating and ensuring stable and reliable power transmission.
Design Advantages
Compact Design: Effectively saves installation space, ideal for limited space environments.
Flexible Power Access: Paired with Hongmao power take-off units, it allows for quick and convenient power access without interrupting the power supply, enhancing system adaptability and operational flexibility.
Seven-Line System Features: Provides more options for power lines, enhancing the system's power distribution capabilities and flexibility, meeting the needs of complex electrical layouts.
Technical Parameters
| Product category | L7-5P/ S7-5P |
| Climatic Min./Max./Average over 24h | -5/+40/35℃ |
| Ingress Protection | IP40 |
| Isolating material | Aluminum Alloy、PVC |
| Isolating colour | RAL7032、RAL7035 |
| Rated Isolating Voltage | 400V |
| Rated operating Voltage | 380V |
| Rated Frequency | 50Hz |
| Rated Current | 30A～100A |
| Rated current short tolerance | 8kA |
| Rated current short tolerance lpk | 12kA |
| Isolating of Bar | Cu |
| Maximum installation spacing | 1.4m |
| Voltage Category/Pollution Degree | III |
Product Uses
Suitable for various scenarios, especially those requiring flexible power distribution, such as garment production workshops and machinery production workshops. The seven-line design is particularly suitable for environments needing multiple power lines and complex electrical layouts.
In conclusion, the Seven-Line Lighting Busbar System combines high efficiency, multifunctionality, and a compact design to offer a safe, efficient, and adaptable power distribution solution. This product not only meets the high standards required by modern industrial and commercial environments for power systems but also represents a significant advancement in busbar technology in the field of power distribution.
